BCB Solution manufactures various types of Diesel Generator up to 3750kVA, 415V Class range to meet the customer requirements which can be provided with the following type
- 7.5-58.5kVA
- 58.5-160kVA
- 180-500kVA
- 500-3750kVA
7.5-58.5kVA
The Diesel Generator 7.5- 58.5 KVA Set 2.5 – 3.6 Series is a high-performance, designed to meet the stringent CPCB IV+ emission norms while providing efficient, reliable power. It is available in two prime power ratings: 50 kVA / 40 kWe and 58.5 kVA / 47 kWe
Key Highlights / Features
- Latest Technology: State-of-the-art Cummins® X3.6 engine paired with the Stamford alternator ensures unmatched performance and durability.
- Low Operating Costs: Delivers maximum efficiency even at part loads, with a 500-hour/18-month service interval and a best-in-class comprehensive warranty.
- Environmentally Friendly: Meets CPCB IV+ norms with advanced emission control systems, offering cleaner, quieter operation.
- Compact & Efficient: With a superior power-to-weight ratio and a compact design, it is ideal for varied industrial and commercial applications.
- Comprehensive Support: Backed by Cummins India’s extensive customer support network, offering 24/7 service and spares across the country.
Technical Specifications
- Engine: Cummins® X3.6 series, 4-cylinder, radiator-cooled, turbocharged intercooled engine
- Fuel Efficiency: Common rail electronic injection system for optimized fuel consumption
- Alternator: Stamford S2L1 series, brushless, screen-protected, revolving field alternator
- Control Panel: Cummins PowerStart™ PS0602 with remote start-stop, intuitive display, and advanced metering and protection features
- Soundproofing: Acoustic enclosure with CRCA sheets and noise reduction insulation, maintaining noise levels below 75 dBA
This generator set is designed for optimal performance, offering a rugged solution for prime power needs in diverse environmental conditions, including high altitudes.
58.5-160kVA
Diesel Generator 15-25 KVA Set 1.5-2.5 Series: A compact and efficient power solution designed for small to medium applications, 58.5-160kVA
series meets stringent emission standards while delivering reliable performance. Available in prime power ratings of 20 kVA / 16 kWe and 25 kVA / 20 kWe.82.5- 140 KVA
Key Highlights / Features
- Engine : Cummins® QSB4.5 Series engine, a 4-cylinder, turbocharged, charge air-cooled engine for optimal performance.
- Fuel System : Advanced common rail electronic fuel system ensuring optimized fuel consumption.
- Cooling System : Liquid-cooled for ambient temperatures up to 50°C.
- Alternator : Stamford alternator with best-in-class efficiency, IP23 enclosure, and ±0.5% voltage regulation.
- Noise Compliance : Built to meet stringent MoEF/CPCB norms with hospital-grade silencers for noise levels of 75 dBA at 75% load.
- Compact Design : Ensures optimal power-to-weight ratio and enhanced portability.
- Eco-Friendly : Engineered to minimize emissions, using an in-cylinder solution and exhaust after-treatment to comply with environmental standards.
- Cost-Efficient : Designed to offer the lowest operating cost in its class with extended service intervals and a comprehensive warranty.
- Reliability: Robust design with minimal maintenance requirements, including easy-access components for routine servicing.
Technical Specifications
- Power Output : Ranging from 82.5 kVA to 140 kVA (Prime duty).
- Voltage and Frequency : 415 V, 50 Hz.
- Cooling System : Radiator cooled, designed for high ambient temperatures.
- Noise Levels: Hospital-grade silencers ensure low-noise operation, with noise emissions under 75 dBA.
Additional Benefits
- Advanced Control Panel : Featuring the Cummins® PowerStart™ PS0602 Controller, offering real-time monitoring, remote start-stop functionality, and advanced engine protection.
- Comprehensive Warranty : Industry-leading warranty covering the entire generator set, including critical components like rubber elements.
- Service Network: Cummins’ vast support network ensures round-the-clock service and parts availability across India.
180-500kVA
Diesel Generator 30-75 KVA Set 3-4.5 Series: Engineered for versatility and reliability, the 180-500kVA series offers robust power generation with reduced emissions, making it ideal for commercial and industrial uses. Prime power ratings available include 50 kVA / 40 kWe and 75 kVA / 60 kWe.
Product Overview
- Model : Diesel Generator Set QSM15 Series
- Power Rating : 380 – 500 kVA (304 – 400 kWe Prime)
- Emission Compliance : CPCB IV+ Emission Compliant
- Engine: Cummins® QSM15 series, a 6-cylinder, in-line, 4-stroke, radiator-cooled engine with advanced technology for high performance and low emissions.
Key Highlights / Features
- Superior Technology & Performance:
- Powered by the Cummins® QSM15 series engine and a world-class Stamford alternator.
- Exhaust after-treatment and in-cylinder solution to meet stringent emission norms.
- Compact in size with an optimum power-to-weight ratio.
- Fuel System & Efficiency:
- Equipped with a common rail electronic fuel injection system for optimized fuel consumption.
- Spin-on single fuel filter with a water separator and full-flow spin-on lube oil filter.
- Cooling system designed for 50°C ambient conditions.
- Environmental Benefits:
- Class-defining, technologically advanced engine to meet the latest MoEF emission regulations.
- Low noise levels with hospital-grade silencers ensuring minimal sound pollution.
- Operational Economy & Durability:
- Offers the lowest operating cost in its class, with a service interval of 500 hours/1 year.
- Best-in-class comprehensive warranty covering the entire generator set, including rubber components.
- Single Source Power Assurance:
- All components, including engine, alternator, control system, and canopy, are designed and manufactured by Cummins India.
- India’s largest and best customer support network for 24/7 service
Control Panel & Monitoring
- Equipped with Cummins® PowerStart™ PS0602 Controller for microprocessor-based monitoring and control.
- LCD display with remote start-stop functionality, data logging, and alarm systems.
- Provides protection features like low lube oil pressure, high/low coolant temperature, over/under voltage, and more.
Alternator Specifications
- Make : Stamford (CGT)
- Enclosure : IP 23, H Class Insulation.
- Best in class efficiency with low Total Harmonic Distortion (THD).
Acoustic Enclosure
- Designed to meet stringent MoEF/CPCB norms of 75 dBA @ 1mtr .
- Constructed from CRCA sheets with UV-resistant powder coating and high-quality noise absorbent insulation.
Maintenance & Service
- Service intervals every 500 hours/1 year.
- Comprehensive warranty, including on rubber components.
500-3750kVA
Diesel Generator 100-250 KVA Set 6-10 Series: Delivering exceptional performance and durability, the 500-3750kVA series is designed for heavy-duty applications, exceeding industry standards for efficiency and emissions. Available in prime power ratings of 150 kVA / 120 kWe and 250 kVA / 200 kWe.
Key Highlights / Features
- Advanced Technology
- Cummins® QSK19 series engine
- Equipped with Cummins New Electronic Fuel System
- Exhaust after-treatment for emission control
- Compact size, superior power-to-weight ratio
- World-class Stamford alternator
- Environmentally Friendly
- Class-leading engine technology adheres to stringent MoEF emission norms
- Designed for low noise levels
- CPCB IV+ Emission Compliant
- Cost-Efficiency and Reliability
- Maximum efficiency at partial loads ensures low operating costs
- 500-hour/1-year service interval
- Comprehensive warranty covering all components, including rubber parts
- Seamless Integration
- Cummins designs, manufactures, and tests the entire system for optimum performance
- One-stop power assurance with a fully integrated engine, alternator, control system, and after-treatment solution
Engine Specifications
- Type: 6-cylinder, In-line, 4-stroke
- Fuel System: Electronic Common Rail Injection
- Power Output: 888 hp
- Cooling: Liquid cooled (50°C ambient rating)
- Aspiration: Turbocharged, Charge-Air Cooled
- Capacity: 19 liters, 14.7:1 compression ratio
Alternator Specifications
- Make: STAMFORD (CGT)
- Voltage Regulation: ±1%
- Efficiency: Best-in-class, sealed bearings for durability
- H-Class Insulation
- Low harmonic distortion (<5%)
Control Panel (PS0602 Controller)
Features:
- LCD display, microprocessor-based monitoring
- AMF functionality
- CAN Compatible
- Data logging and maintenance alerts
- Modbus Interface (RS485 RTU)
- Remote monitoring with 4G capability
Acoustic Enclosure
- Noise Level: 75 dBA@1mtr at 75% load
- Material: CRCA sheets with fire-retardant Rockwool insulation
- Finish: UV-resistant powder coating
- Compliance: Meets CPCB IV+ norms for noise and emission
Maintenance and Support
- Comprehensive Warranty: Industry-leading coverage for engine, alternator, and other components
- Service Interval: 500 hours/1 year
- Customer Support: Largest support network in India, offering 24/7 service availability
